FORE:3. Two elevations taken at right angles to each other, fix all points, and give all dimensions of parts that have their axis parallel to the planes on which the views are taken; but when a machine is complex, or when several parts lie in the same plane, three and sometimes four views are required to display all the parts in a comprehensive manner.In casting and forging operations the material is treated while in a heated and expanded condition; the nature of these operations is such that accurate dimensions cannot be attained, so that both forgings and castings require to be made enough larger than their finished dimensions to allow for shrinkage and irregularities. Finishing as a process consists in cutting away this surplus material, and giving accurate dimensions to the parts of machinery when the material is at its natural temperature. Finishing operations being performed as said upon material at its normal temperature permits handling, gauging and fitting together of the parts of machinery, and as nearly all other processes involve heating, finishing may be called the cold processes of metal work. The operations of a fitting shop consist almost entirely of cutting, and grinding or abrading; a proposition that may seem novel, yet these operations comprehend nearly all that is performed in what is called fitting.
